Key Features
- IP69K waterproof casing: ultimate protection against dust, high-pressure water, and steam
- Higher GNSS accuracy with up to 41 visible satellites
- Wide 10–90V power supply for motorcycles, e-bikes, e-mopeds, e-rickshaws, and other two-wheelers
- Optimized sleep modes for extended operation and reduced battery drain
- Jamming detection and auto geofence scenario
- Bluetooth 4.0 + LE for driver ID and sensor connectivity
Technical Specifications
Feature | Specification |
Connectivity | 4G LTE Cat 1 |
Dimensions (L x W x H) | 118 x 48 x 18.5 mm |
Power Supply | 10–90V DC |
Connector Type | 5-pin |
Ingress Protection | IP69K |
Internal Battery | 320 mAh Li-ion 3.7V |
GNSS Antenna | Internal |
Digital Inputs | 1 |
Digital Outputs | 1 |
Analog Inputs | 1 |
