Key Features
- 8-channel 1080p AHD video input for full vehicle surround coverage
- H.265/H.264 compression for efficient high-quality video storage
- Support for up to 4 x 2MP IP cameras via 6-PIN aviation Ethernet port
- Built-in 4G for real-time video streaming and remote access
- Built-in GPS for precise vehicle location tracking
- Built-in Wi-Fi for automatic video offload when vehicle returns to depot
- 6-axis G-sensor for detailed crash detection and event recording
- Up to 4TB HDD/SSD storage + 512GB SD card for extensive video archives
- Wide voltage range 8–36V for compatibility with cars, vans, trucks, and buses
- RS232 x3 and RS485 x1 for integration with external devices and sensors
- Full AI safety suite — ADAS, DMS, Face Recognition, BSD, and PCC
Technical Specifications
Feature | Specification |
Video Channels | 8 x AHD 1080p input |
IP Camera Support | Up to 4 x 2MP IPC |
Video Compression | H.265 / H.264 |
Video Output | AHD 1080p |
Storage — SD Card | 1 x SD card slot, max 512GB |
Storage — HDD/SSD | 1 x HDD/SSD slot, max 4TB |
Built-in 4G | Yes |
Built-in GPS | Yes |
Built-in Wi-Fi | Yes |
G-Sensor | 6-axis |
Ethernet Port | 6-PIN aviation Ethernet |
Power Supply | 8–36V DC wide range |
AI Features | ADAS, DMS, Face Recognition, BSD, PCC |
